Premium mobile printing and RFID capabilities for maximum productivity
Always on the edge of innovation, Zebra offers premium RFID mobile printers to give your workers a leading advantage. The ZQ630 Plus RFID rounds out Zebra's ZQ600 Plus Series printers with advanced technology and innovative design that drive productivity, ease-of-use and manageability to a new level. Save time, reduce errors, print and encode RFID labels and tags on the spot with ease. A large color display takes all the guesswork out of printer status. Advanced battery technology and more battery capacity-6600 mAh-power every minute of the longest shift. The instant wake-up feature on Wi-Fi™ or Bluetooth® ensures the ZQ630 Plus RFID never sleeps on the job. And, the ZQ630 Plus RFID is easier to integrate, manage, setup and secure, thanks to Zebra's Link-OS® printer operating system and powerful Print DNA™ suite of applications, utilities and developer tools.
Premium Features for Maximum Productivity | RFID + Mobility Made Easy
Leading the industry in RFID mobility, Zebra was the first to introduce RFID mobile printers in the market.. The innovative ZQ630 Plus RFID printer gives your workers the flexibility to print and encode RFID labels with ease. Compatible with all current Zebra RFID technology, including tags and encoding schemes, it's easy to extend RFID to a mobile printer.
RFID setup is simple with automatic calibration features that eliminate complex RFID placement guidelines. Insert the RFID media into the ZQ630 Plus and RFID calibrate only once-no need to recalibrate with same-type media changes.
The Industry's First Wi-Fi 6 Mobile Printer
The ZQ630 Plus RFID offers fast, dependable wireless connections for your inside-the-four-walls applications. Take advantage of your Wi-Fi 6/6E network upgrade and get best-in-class WPA3 security, lightning-fast speeds and enhanced roaming. For flexibility, choose between 802.11ax/Bluetooth 5.3 or 802.11ac/Bluetooth 4.2 dual radio options, depending on your network environment.
Industry-Standard 802.11r Fast Roaming for Seamless Access
With support for 802.11r fast roaming technology, your workers can depend on a connection while they are on the move.
Business Tough-Built for All-Day Every Day Enterprise Use
While the ZQ630 Plus RFID is lightweight and comfortable to wear all shift long, it is loaded with features that give it long-lasting durability, including over-molding, a tempered-glass display and seamless one-piece design. The high-grade resin is one of the toughest plastics available for greater impact resistance.
Superior Battery Power and Power Management | Do More on a Single Charge
With the ZQ630 Plus RFID's high-capacity battery, you can be sure that every worker has plenty of power for every shift.
Plus Power Smart Print Technology™, Zebra's patented technology, maximizes efficiency by delivering the exact amount of power required for the highest quality printing, saving an estimated 20 to 30 percent of battery power.
Extraordinary Battery Management Capabilities
The ZQ630 Plus RFID's PowerPrecision+ battery delivers the ultimate in battery power and management. A wealth of easily accessible battery metrics makes it easy to identify aging batteries before they impact productivity.
Features
Apple® iOS, Android™ and Windows® Mobile connectivity
Direct thermal printing of barcodes, text and graphics
CPCL, EPL™ and ZPL® programming languages
512 MB Flash supports downloadable programs, receipt formats, fonts and graphics (128 MB available for user storage)
6600 mAh (nominal) 47.5 Wh removable, rechargeable PowerPrecision + Li-Ion battery
Built-in battery charger
Belt clip for unobtrusive and convenient printing Black mark sensing using fixed center position sensors
Easy-to-use peel and present mode Label present sensor for issuing labels one at a time
Tear bar for easy media dispensing
Center-loading media locking for variable roll widths
"Clamshell" design for easy media loading
Technical Specs
Power Description
Power Source Battery
Software
Operating System Supported
Link-OS
Display & Graphics
Display Screen Yes
Screen Size 10.2 cm (4")
Technical Information
Application/Usage Healthcare
Warehouse
Retail
Transportation & Logistic
Manufacturing
Mobile
Barcode Symbology Supported Plessey
POSTNET
QR Code
TLC 39
2 and 5 Digits Add-on
2D
AZTEC
Codabar (NW-7)
Code 128
Code 39
Code 93
UCC/EAN 128
UPC-A
UPC-E
PDF417
MSI
Micro PDF-417
Maxi Code
FIM Postnet
GS1 DataBar (RSS)
Interleaved 2 of 5
FIM
EAN-8
EAN-13
Data Matrix
Maximum Print Width 104 mm (4.09")
Recommended Use Label Print
Features Water Resistant
Belt Clip
Dust Resistant
Mobile Device Printing Yes
Print Color Capability Monochrome
Maximum Print Length 813 mm
Character Sets Universal Font Scaling Technology (UFST)
Thai
Agfa Monotype
Korean
Ingress Protection (IP) Rating IP54
Maximum Print Resolution (dpi) 203
Interfaces/Ports
USB Yes
USB Host Yes
Memory
Flash Memory 512 MB
Standard Memory 256 MB
Battery Information
Battery Chemistry Lithium Ion (Li-Ion)
Battery Capacity 6600 mAh
Battery Included Yes
Miscellaneous
Platform Supported iOS
Android
Energy Star Yes
Fonts & Emulation
Language Emulation EPL
CPCL
XML
ZPL
Physical Characteristics
Weight (Approximate) 1.11 kg
Height 82.5 mm
Width 165 mm
Depth 187 mm
Network & Communication
Bluetooth Yes
Ethernet Yes
Wireless LAN Yes
Ethernet Technology Fast Ethernet
RFID Yes
Network Ready Yes
Near Field Communication (NFC) Yes
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ63RAXAA0400
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ630 Plus
Product Name ZQ630 Plus Direct Thermal Printer
Product Series ZQ600
Brand Name Zebra
Media Types & Handling
Media Thickness 190.5 µm
Maximum Roll Diameter 66 mm
Media Type Receipt
Tag
Label
Die-cut Label
Linered Media
Black Mark
Black Bar
Media Sensor Black Mark Sensor
Label Present Sensor
Gap Sensor
Maximum Label Width 112 mm
Maximum Label Length 813 mm
