Product Description
Premium mobile printing and RFID capabilities for maximum productivity
Always on the edge of innovation, Zebra offers premium RFID mobile printers to give your workers a leading advantage. The ZQ630 Plus RFID rounds out Zebra's ZQ600 Plus Series printers with advanced technology and innovative design that drive productivity, ease-of-use and manageability to a new level. Save time, reduce errors, print and encode RFID labels and tags on the spot with ease. A large color display takes all the guesswork out of printer status. Advanced battery technology and more battery capacity-6600 mAh-power every minute of the longest shift. The instant wake-up feature on Wi-Fi™ or Bluetooth® ensures the ZQ630 Plus RFID never sleeps on the job. And, the ZQ630 Plus RFID is easier to integrate, manage, setup and secure, thanks to Zebra's Link-OS® printer operating system and powerful Print DNA™ suite of applications, utilities and developer tools.
Premium Features for Maximum Productivity | RFID + Mobility Made Easy
Leading the industry in RFID mobility, Zebra was the first to introduce RFID mobile printers in the market.. The innovative ZQ630 Plus RFID printer gives your workers the flexibility to print and encode RFID labels with ease. Compatible with all current Zebra RFID technology, including tags and encoding schemes, it's easy to extend RFID to a mobile printer.
RFID setup is simple with automatic calibration features that eliminate complex RFID placement guidelines. Insert the RFID media into the ZQ630 Plus and RFID calibrate only once-no need to recalibrate with same-type media changes.
The Industry's First Wi-Fi 6 Mobile Printer
anced roaming. For flexibility, choose between 802.11ax/Bluetooth 5.3 or 802.11ac/Bluetooth 4.2 dual radio options, depending on your network environment.
Industry-Standard 802.11r Fast Roaming for Seamless Access
With support for 802.11r fast roaming technology, your workers can depend on a connection while they are on the move.
Business Tough-Built for All-Day Every Day Enterprise Use
While the ZQ630 Plus RFID is lightweight and comfortable to wear all shift long, it is loaded with features that give it long-lasting durability, including over-molding, a tempered-glass display and seamless one-piece design. The high-grade resin is one of the toughest plastics available for greater impact resistance.
Superior Battery Power and Power Management | Do More on a Single Charge
With the ZQ630 Plus RFID's high-capacity battery, you can be sure that every worker has plenty of power for every shift
Plus Power Smart Print Technology™, Zebra's patented technology, maximizes efficiency by delivering the exact amount of power required for the highest quality printing, saving an estimated 20 to 30 percent of battery power.
Extraordinary Battery Management Capabilities
The ZQ630 Plus RFID's PowerPrecision+ battery delivers the ultimate in battery power and management. A wealth of easily accessible battery metrics makes it easy to identify aging batteries before they impact productivity.
Features
Apple® iOS, Android™ and Windows® Mobile connectivity
Direct thermal printing of barcodes, text and graphics
CPCL, EPL™ and ZPL® programming languages
512 MB Flash supports downloadable programs, receipt formats, fonts and graphics (128 MB available for user storage)
6600 mAh (nominal) 47.5 Wh removable, rechargeable PowerPrecision + Li-Ion battery
Built-in battery charger
Belt clip for unobtrusive and convenient printing
Black mark sensing using fixed center position sensors
Easy-to-use peel and present mode
Label present sensor for issuing labels one at a time
Tear bar for easy media dispensing
Center-loading media locking for variable roll widths
"Clamshell" design for easy media loading
Technical Specs
Display & Graphics
Display Screen Yes
Interfaces/Ports
USB Host Yes
Power Description
Power Source Battery
Software
Operating System Supported Link-OS
Technical Information
Application/Usage Desktop
Healthcare
Industrial
Manufacturing
Mobile
Retail
Warehouse
Transportation & Logistic
Barcode Symbology Supported Data Matrix
Code 93
Code 39
Code 128
Codabar (NW-7)
AZTEC
Maxi Code
UPC E with 2 and 5 add on
UCC/EAN 128
TLC 39
QR Code
POSTNET
PDF417
MSI PLESSEY
Micro PDF-417
UPC-A
Interleaved 2 of 5
GS1 DataBar
FIM
EAN-8
2 and 5 Digits Add-on
EAN-13
Maximum Print Width 104 mm (4.09")
Recommended Use Label/Receipt Print
Connectivity Technology Wireless
Features Dust Resistant
Water Resistant
Belt Clip
Shoulder Strap
Mobile Device Printing Yes
Print Color Capability Monochrome
Maximum Print Length 813 mm
Character Sets Agfa Monotype
Universal Font Scaling Technology (UFST)
Ingress Protection (IP) Rating IP54
Maximum Print Resolution (dpi) 203
Memory
Flash Memory 512 MB
Standard Memory 256 MB
Battery Information
Battery Chemistry Lithium Ion (Li-Ion)
Battery Capacity 6800 mAh
Battery Included Yes
Physical Characteristics
Weight (Approximate) 1.10 kg
Height 82.6 mm
Width 165.1 mm
Depth 186.7 mm
Fonts & Emulation
Language Emulation CPCL
EPL
ZPL
ZBI 2.0
XML
Miscellaneous
Platform Supported iOS
Android
PC
Energy Star Yes
Power Cable Localization India
Network & Communication
Bluetooth Yes
Ethernet Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Ethernet Technology Fast Ethernet
Near Field Communication (NFC) Yes
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ63AAXAA0400
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ630 Plus
Product Name ZQ630 Plus RFID Mobile Printer
Product Series ZQ600
Brand Name Zebra
Media Types & Handling
Media Thickness 190.5 µm
Maximum Roll Diameter 66.04 mm
Media Type Tag
Gap
Die-cut Label
Black Mark
Black Bar
Label
Receipt
Linered Media
Media Sensor Black Mark Sensor
Gap Sensor
Label Present Sensor
Maximum Label Width 111.76 mm
Maximum Label Length 812.80 mm
