Product Description
Kyocera ECOSYS devices are designed to do more with less. With long-life components, low energy use, and reliable performance, they help your team work smarter while cutting costs and downtime.
Copy, colour scan and fax functionality
Up to 32/17 PPM in black and white Cloud-ready applications
Minimum installation and operation requirements.
Long-life components provide exceptional reliability.
HyPAS solution platform enables powerful customisations.
Main Specifications:-
General
General type Monochrome multifunctional for A3 format
Engine speed Up to 32/17 pages A4/A3 per minute (print/copy)
Warm-up time 21.5 seconds or less
Power consumption Sleep-mode: less than 0.3 W, Ready mode: 70 W, Copying/Printing: 490 W
Warranty 3 years on-site warranty as standard
Paper Handing
Input capacity 100-sheet multi-purpose tray, 45–256 g/m²: A3, A4, A5, A6, B5, Ledger, Letter, Legal, Folio, Custom (98 x 148 to 297 x 432 mm), 500-sheet standard universal paper cassette; 60–163 g/m², A3, A4, A5,´B5, Ledger, Letter, Legal, Folio
Max. input capacity with options 1,600 sheets
Duplex unit Duplex as standard supports 60–163 g/m²
Max. output capacity Max. 300 sheets: 250 sheets face-down (Main Tray), plus 50 sheets (standard Job Separator Tray)
Document processor Standard reversing document processor: 50-sheet, Simplex scan 45–160 g/m², Duplex scan 50–120 g/m², A3, A4, A5, B5, Letter, Legal, Custom (140x182 to 297x432mm)
Print
Processor
ARM Cortex-A53 (Dual Core) / 1.4GHz
Fonts
Outlines: Outline font:
93 fonts (PCL6)
93 fonts (KPDL3)
4 fonts (Calibri)
4 fonts (Cambria)
Bitmap font: 1 font
79 fonts: processed as outline font
Features Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, Private Print , Quick Copy, Proof and Hold, Job Storage and Job Management functionality
Applicable OS MAC OS X Version 10.9 or higher,Unix, Linux as well as other operating systems on request
Copy
Max. original size A3/Ledger
Continuous copy 1 - 998
Zoom range 25 - 400 % in 1% steps
Preset magnification ratios 5 Reductions/5 Enlargements
Image adjustments Text, Photo, Text + Photo, Graphic/Map
Digital copy features Scan-once-copy-many, electronic sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through, ID card copy, Skip blank page
Scan
Scan functionalities Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA, WSD scan
Scan speed 50 ipm (300 dpi, A4, b/w), 50 ipm (300 dpi, A4, colour)
Scan resolution 300 dpi x 300 dpi(Default),200 dpi x 200 dpi,200 dpi x 100 dpi 600 dpi x 600 dpi,400 dpi x 400 dpi,200 dpi x 400 dpi 1200 dpi x 1200 dpi (only with TWAIN Driver, WIA Driver
Max. scan size A3/Ledger
File type TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u
Original recognition Text, photo, text + photo, light text, optimised for OCR
Fax
Compatibility G3
Modem speed Less than 3 seconds
Scanning speed 2.0 seconds/sheet or less
Transmission speed Max. 33.6 kbps
Max. original size A3/Ledger
Fax features Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast
Scanning density Normal: 8 dot/mm x 3.85 line/mm, Fine: 8 dot/mm x 7.7 line/mm, Superfine: 8 dot/mm x 15.4 line/mm, Ultrafine: 16 dot/mm x 15.4 line/mm, Halftone: 256 gray scales
Options and Consumables
Paper Handing Options
Article Type
PF-470 Paper feeder
Capacity in sheets Max. 500 sheets
Dimensions (W x D x H) 590 x 589 x 352 mm
Paper size 60-163 g/m²; A3, A4, A5, B5, Letter, Legal, Custom (98x148 to 297x432 mm)
PF-471 Paper feeder
Capacity in sheets 1,000 sheets (2 x 500 sheets)
Dimensions (W x D x H) 590 x 589 x 352 mm
Paper size 60-163 g/m²; A3, A4, A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm)
Consumables
TK-6864 Microfine toner black for 15,000 pages A4, Capacity of starter toner is 3,000 pages A4
Options
Scan Extension Kit (A) AC Scan Extension Kit (A) AC Scan to searchable PDF solution (embedded OCR), convert to PDF or MS Office (docx, xlsx, pptx)
Fax System Fax System 14
USB Card Reader + Card Authentication Kit (B) AC Support for various authentication keys available. The card holder is standard
UG-33 AC ThinPrint support
HD-17 64 GB SSD storage for easy document management
HD-18 256 GB SSD storage for easy document management
HD-19 512 GB SSD storage for easy document management
