Brief Overview
The MC853dnct Colour A3 Multi function Printer comes with extra tray and Cabinet, auto duplex printing and and optional wi-fi unit. 3 Year warranty on registration within 30 days. Up to 23ppm Mono & Colour
Product Description
Key Features
Description A3/A4 colour 4-in-1 MFP
Number of users 1 to 25
Printer
Print Speed A4: 23ppm colour/mono; A3: 13ppm colour/mono
Time to first print (TTFP) 14 seconds colour/mono
Warm up time 32 seconds or less from power on
Processor speed 800MHz
Scan
Scan Resolution 600 x 600dpi
Scan Speed Up to 50spm
Colour depth Output 24 bit (8 bit x 3 RGB)
Document input Up to 100 sheet RADF
Contrast 7 Levels
Format PDF/High compression PDF/Secure PDF, TIFF, JPEG, XPS
Addressbook LDAP, 1000 Email addresses, 20 group addresses
Scan to Shared folder (CIFS, FTP, HTTP), E-Mail, USB Memory, Local PC, Remote scan
Copy
First copy out time (FCOT) 14.5 seconds colour/mono
Copy speed 23cpm colour/mono
Copy resolution 300/600dpi
Reduction/Enlargement Zoom 25-400%
Maximum copies 999
Fax
Fax connectivity RJ11 x 2 (Line/Tel) PSTN, PBX
Fax speed ITU-T G3 (Super G3) 33.6kbps
Groups 32
Broadcast Maximum 100
40 one touch dials (8 X 5 using scroll key), 1000 speed dials
8MB (approx 400 pages transmit and receive)
8,000 pages/month
Interface and Software
Connectivity USB 2.0 Device, 10/100/1000 Ethernet, Host USB x 2, Wireless 802.11b/g/n (optional)
Printer language PostScript3(Emulation), PCL5c, PCL6(XL), EPSON FX, IBM ProPrinter, XPS, PDF(v1.7)
Network & protocols All major network protocol supported via
ethernet card with internal web server for printer and network card set
up and management. TCP/IPv4&v6, AirPrint, Google Cloud Print,
NetBIOS over TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS,
UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan,
LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, Secure Protocol
Server, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3,
WLAN802.11b/g/n, WPA2, Personal, Enterprise
OS Compatibility Windows 7 (32-bit & 64-bit), Windows 8 (32-bit
& 64-bit), Windows 8.1 (32-bit & 64-bit), Windows Server 2003
(32-bit & 64-bit), Windows Vista (32-bit & 64-bit), Windows
Server 2008 (32-bit & 64-bit), Windows Server 2008 R2 (64-bit),
Windows Server 2012 (64-bit), Windows Server 2012 R2 (64-bit); Linux
PPD; Mac OS 10.6.8 - 10.7, 10.8, 10.9, 10.10
Advanced networking and security IP Filtering, MAC filtering, SSL/TLS, EAP(IEEE802.1X), IPSec
Utilities Color Correct, OKI LPR, smart PrintSuperVision, Color Swatch,
Template Manager, Web Driver Installer, Firmware Update Tool, Front End
Installer, Network Extension, Print Job Accounting Client, PS Gamma
Adjuster, Profile Assistant, PDF Print Direct, Configuration Tool,
ActKey, Network Card Setup
Document management SENDYS Explorer LITE, ABBYY FineReader 12 Sprint
Operator panel
LCD panel 7" (17.5cm) LCD colour backlit touch screen & key top; 23 Hard Keys, 2 LEDs
Typefaces
Printer fonts Scalable: 87 PCL fonts & 80 PostScript fonts, 4 PCL fonts (Line Printer, OCR-A/B, USPS ZIP Barcode)
Barcodes 10 types of one dimension with 26 variations: UPC-A, UPC-E,
EAN/JAN-8, EAN/JAN-13, Interleaved2of5, Code39, Code 128, EAN/UCC-128,
CODABAR, ZIP+4POSTNET; 2 types of two dimensions : PDF417, QRcode
Print quality
Resolution ProQ 2400 Multi-level technology, 1200 x 600dpi, 600 x 600dpi
Paper Handling
Paper capacity Tray 1: 300 sheets of 80gsm; Multi-purpose tray: 100 sheets of 80gsm; RADF: 100 sheets of 80gsm
Paper capacity optional tray 2nd tray and Cabinet: 535 sheets of 80gsm
(standard on MC853dnct); 2nd/3rd tray and casterbase: 1,070 sheets of
80gsm (standard on MC853dnx)
Maximum paper capacity MC853dn: 400 sheets of 80gsm; MC853dnct: 935 sheets of 80gsm; MC853dnx: 1,470 sheets of 80gsm
Paper sizes Tray 1: A3, A4, A5, A6, B4, B5; Tray 2/3/4: A3, A4, A5, B4,
B5; Multi-purpose tray: A3, A4, A5, B4, B5, A6, B6; 11 Envelopes
(Com-10, DL, Monarch, C5, C4), Custom size (up to 1321mm length
including banner); RADF: A3, A4, A5, A6, B4, B5; Duplex: A3, A4, A5, B4,
B5. Supports custom size: Width 148.5-297mm Length: 210-431.8mm
Paper weight Tray 1: 64 to 220gsm; Tray 2/3/4: 64 to 176gsm;
Multi-purpose tray: 64 to 256gsm; RADF: 60 to 120gsm; Duplex: 60 to
120gsm
Duplex Standard
Paper output Face up: 100 sheets (80gsm) Face down: 1st bin: 250 sheets (80gsm) 2nd bin: 100 sheets (80gsm)
General Features
Memory (RAM) 1.26GB
Memory (Hard Disk Drive) 250GB
Operating temperature/ humidity 10°C to 32°C (17°C to 27°C recommended) / 20% to 80% RH (50% to 70% RH recommended)
Storage temperature/ humidity -10°C to 43°C / 10% to 90% RH
Power supply Single phase 220–240VAC, frequency 50/60Hz +/- 2%
Power consumption Typical: <850W; Max: <1400W; Idle: <120W (average); Power Save: ≦30W; Deep Sleep: ≦3W
Noise level Operating: 54dB(A) or less; Standby: 37dB(A) or less; Power save: Background level
Dimensions (HxWxD) MC853dn: 700 x 563 x 600mm; MC853dnct: 1216 x 563 x 600mm; MC853dnx: 1078 x 563 x 600mm
Weight MC853dn: 64kg; MC853dnct: 93.4kg; MC853dnx: 86.6kg
Duty cycle (Maximum) 60,000 pages/month
Warranty 3 years extended warranty upon registration within 30 days of purchase
What's in the box?
Printer is shipped with toners that do CMYK = 2500 prints
Power cord
Disk, (manual + Drivers)
Product Specifications
Up to 23ppm Mono & Colour
Up to Print Resolution 2400 dpi
300 Sheet Input Tray
800 MHz Processor
Automatic Double Sided Printing
USB & Network
* = 3 year warranty on registration within 30 days of invoice.
Brochure for Oki MC853dnct A3 Colour Multifunction Printer
