Product Description
FAST AND RELIABLE CARD PRINTING WITH PHOTO-LIKE IMAGES
Print outstanding, high-quality cards using the latest in card-printing technology with Zebra's ZXP Series 7â„¢ card printer. Get fast and reliable performance along with exceptional value with printer's lower total cost of ownership. Time after time, it prints sharp vivid cards with precise color control.
The ZXP Series 7 printer has an innovative design. It automatically adjusts to the thickness of the card, and ribbon loading is easy. With color-coded guides and a clear LCD control panel, it's simple for anyone to use. Locking mechanisms protect the printer and media, and software provides further security by tracking and restricting activities as required.
SUPERIOR PERFORMANCE | Card After Card
Built to meet your demanding business environment, the ZXP Series 7 printer features a robust design and premium out-of-the-box performance for a wide range of environments and applications. It generates near-photographic print quality and color depth using photo-print technology, along with edge-to-edge printing. Add lamination to ensure card security and lengthen the life of images.
HIGH PRODUCTIVITY | Print More Cards Faster
Reduce wait time with fast print speeds, including click-to-drop and batch printing. The ZXP Series 7 offers the fastest throughput with simultaneous dual-sided lamination and the ability to process up to three jobs at the same time (encoding, printing and laminating simultaneously). Add more speed with ix Seriesâ„¢ ribbons, developed for faster printing.
GET PRINTING, KEEP PRINTING | Easy Setup and Low Maintenance
Easily integrate and maintain your ZXP Series 7 printer with smart features such as simplified ribbon loading and operation, high-capacity media, and synchronized ribbon and laminate rolls. Deploy printers quickly with Windows® drivers, ZMotif™ SDK and networking options.
ZXP SERIES 7 PRO MODEL | Complete Large Print Jobs Quickly
The ZXP Series 7 Pro is designed for service bureaus and governments to quickly issue large quantities of secure identification cards with photo-quality images. It offers larger card hoppers, synchronized supplies and cards and allows you to produce more cards in less time. And, it's less expensive to own than any other printer in its category.
INTELLIGENT ADAPTABILITY | Tailor for Your Needs - Now and Next
Get the flexibility to add options when you need them. Build your portfolio of card-printing applications and manage your investment at the same time with options including single- or dual-sided printing, numerous encoding and connectivity options such as UHF encoding and 802.11b/g wireless connectivity, an integrated barcode reader, wasteless single- or dual-sided lamination, Zebra® Duo-Print™ dual-sided printing upgrade kit and a variety of ribbon options.
Software Adaptability and Control
Administrators can customize feature sets and user privileges with advanced security settings. Software developers can use the ZMotif SDK to integrate advanced features or write custom print applications easily. The ZXP Toolbox allows advanced control over the printer, driver and software setup, administration, and diagnostics.
300 dpi/11.8 dots per mm print resolution
USB 2.0 and Ethernet 10/100 connectivity
Microsoft® Windows Certified drivers
15-card reject hopper (30 mil)
ZXP Series 7 and Series 7 Pro: 250-card input capacity feeder (30 mil)
ZXP Series 7: 100-card output hopper (30 mil)
ZXP Series 7 Pro: 250 First-in, First-out mechanical output hopper
Single-card feed capability
ix Series intelligent media technology
21-character x 6-line LCD operator display with configurable soft keys
Kensington® physical lock slot
Two-year limited warranty on printer and printhead
Tech Specification:-
USB Yes
Display Screen Yes
Display Screen Type LCD
Frequency 60 Hz, 50 Hz
Ethernet Yes
Wireless LAN Yes
Ethernet Technology Fast Ethernet
Platform Supported PC
Certifications & Standards FCC Class A
Power Cable Localization AUS, NZ
Weight (Approximate) 12.20 kg
Height 304.8 mm
Width 698.5 mm
Depth 276.9 mm
Product Type Dye Sublimation/Thermal Transfer Printer
Manufacturer Part Number Z72-RM0C0000AU00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZXP Series 7
Product Name ZXP Series 7 Card Printer
Product Series ZXP
Brand Name Zebra
Media Size ID-1 Card
CR-80 Card
Media Thickness 1270 µm
Media Type Teslin Composite Card
Smart Card
PVC Composite
PVC Card
PETG Card
PETF Card
ABS Card
PET Card
Application/Usage Retail
Hospitality
Healthcare
Academic
High Security
Recommended Use RFID Card Printer
Features Smart Card Contact Station
RFID Encoder
Magnetic Stripe Encoder
Printing Capability Double-Sided
Print Color Capability Colour
Maximum Print Resolution (dpi) 300
