Product Description
Designed to strike the ideal balance between performance and value, the ZT510 includes the core features you need in an industrial printer at a cost-effective price point. Building on the legacy of its industry-leading predecessor, the Zebra® 105SL Plus ™, the ZT510 provides a proven, durable design and construction while adding advanced management and monitoring capabilities. That means you get 24/7 reliability to keep your operations running smoothly today, plus longevity and advanced functionality to power through every challenge in the years to come-all at an exceptional value.
Outstanding performance at an understated price
Zebra's industrial printers are well-known for their durability, fast print speed, long life span and unparalleled reliability. The budget-friendly ZT510 carries on that legacy, with:
24/7 reliability to eliminate downtime
You need printing systems that can support your critical processes and keep you ahead of increasing demands. The ZT510 features Zebra's world-renowned, high-quality print mechanisms and internal components to ensure flawless 24/7 performance, provide consistently outstanding quality and virtually eliminate costly downtime.
Unrivaled durability in the toughest conditions
With an all-metal design, rugged construction and sealed dome buttons to prevent ingress of dust, dirt and moisture, the ZT510 is right at home in today's harshest manufacturing and warehouse environments. This durable workhorse is engineered to withstand years of continuous operation, plus extreme temperatures, debris, rough handling and more.
Value that won't break your budget
The ZT510 is ideal for cost-conscious companies, offering next-generation print performance at an exceptional value. It provides high duty cycle, rugged reliability, fast processing, advanced Link-OS™ capabilities and all the basic features you need-without the added cost of those you don't. It's even ENERGY STAR® qualified to further protect your bottom line.
A variety of connectivity options for flexible configuration
Featuring a variety of standard communication options including USB, Serial, Gigabit Ethernet and Bluetooth® LE, the ZT510 is easy to integrate into existing systems and connect to various networks. Optional Parallel, 802.11a/c with Bluetooth® 4.0, USB Host and IPv6 are also available.
Features
Print Methods: Thermal transfer and direct thermal printing
Construction: Metal frame
Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
Communications: USB, Serial, Gigabit Ethernet, Bluetooth® LE
Backlit, multi-line display including an intuitive menu, easy-to-use keypad and password protection
Technical Specs
Memory
Standard Memory 512 MB
Power Description
Power Source AC Supply
Interfaces/Ports
USB Yes
Serial Port Yes
Network & Communication
Bluetooth Yes
Ethernet Yes
Near Field Communication (NFC) Yes
Miscellaneous
Platform Supported Android
iOS
PC
Energy Star Yes
General Information
Product Type Thermal Transfer Printer
Manufacturer Part Number ZT51043-T0P0000Z
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZT510
Product Name ZT510 Thermal Transfer Printer
Brand Name Zebra
Physical Characteristics
Weight (Approximate) 22.70 kg
Height 395.7 mm
Width 268.2 mm
Depth 512.3 mm
Technical Information
Application/Usage Desktop
Maximum Print Width 104 mm (4.09")
Recommended Use Label Print
Print Color Capability Monochrome
Maximum Print Length 2540 mm
Maximum Print Resolution (dpi) 300
Media Types & Handling
Maximum Roll Diameter 203 mm
Media Type Reflective
Notch
Die-cut Label
Continuous Label
Black Mark
Label
Maximum Label Width 114 mm
Product Specifications
Max. Print Speed 356mm sec.
Max. Print Resolution 300 dpi
Max. Roll Diameter 203 mm
512 MB Standard Memory
ZPL, ZPLII Printer Languages
USB, Ethernet & Bluetooth
One-Year Limited Warranty
