Product Description
Premium mobile label and receipt printers for maximum productivity
Want to improve inventory management and customer service in your store? With the ZQ600 Plus Series mobile printer, you can. The ZQ600 Plus Series takes Zebra's popular QLn platform and makes it even better-adding advanced technology and innovative design that drive productivity, ease-of-use and manageability to a new level. A large color display takes all the guesswork out of printer status. Advanced battery technology and more battery capacity, power every minute of the longest shift. The instant wake-up feature ensures the ZQ600 Plus Series never sleeps on the job. Your workers get the fast, dependable wireless connections and your IT department will find the ZQ600 Plus Series easier to integrate, manage, setup and secure thanks to Zebra's Link-OS® printer operating system and powerful Print DNA suite of applications, utilities and developer tools. ZQ600 Plus Series- the next evolution in the gold standard for mobile label and receipt printing.
Premium Features for Maximum Productivity | The Industry's First Wi-FiTM6 Mobile Printer
The ZQ600 Plus Series offers fast, dependable wireless connections for your inside-the-four-walls applications. Take advantage of your Wi-Fi 6/6E network upgrade and get best-in-class WPA3 security, lightning-fast speeds and enhanced roaming. For flexibility, choose between 802.11ax / Bluetooth® 5.3 or 802.11ac / Bluetooth 4.2 dual radio options, depending on your network environment.
Industry-Standard 802.11r Fast Roaming for Seamless Access
With support for 802.11r fast roaming technology, your workers can depend on a connection while they are on the move.
Instant Wake-Up Over Wi-Fi
This intelligent printer enters sleep mode when it is idle, and automatically wakes up the moment the user sends a print job. And the ZQ600 Plus Series' instant wake-up works over both Wi-Fi and Bluetooth.
Large Color Display Makes Configuration and Operation a Snap
The ZQ600 Plus Series provides a large display, user-friendly interface and easily customized menu. The ZQ600 Plus Series is based on Zebra's Link-OS menu system to deliver a common user experience across other Zebra Link-OS mobile, desktop and industrial printers.
Business Tough-Built for All-Day Every Day Enterprise Use
While the ZQ600 Plus Series is lightweight and comfortable to wear all shift long, it is loaded with features that give it long-lasting durability, including over-molding, a tempered-glass display and seamless one-piece design. The high-grade resin is one of the toughest plastics available for greater impact resistance.
Unsurpassed Battery Power Management | Do More on a Single Charge
With the ZQ600 Plus Series' high-capacity battery, you can be sure that every worker has plenty of power for every shift.Plus Power Smart Print Technology™, Zebra's patented technology, maximizes efficiency by delivering the exact amount of power required for the highest quality printing, saving an estimated 20 to 30 percent of battery power.
Extraordinary Battery Management Capabilities
The ZQ600 Plus Series' PowerPrecision+ battery delivers the ultimate in battery power and management. A wealth of easily accessible battery metrics makes it easy to identify aging batteries before they impact productivity.
Features
Apple® iOS, Android™ and Windows® Mobile connectivity
Direct thermal printing of barcodes, text and graphics
CPCL, EPL™ and ZPL® programming languages
512 MB Flash supports downloadable programs, receipt formats, fonts and graphics (128 MB available for user storage)
ZQ620 Plus and ZQ610 Plus: 3250 mAh (nominal) 23.4 Wh removable, rechargeable PowerPrecision+ Li-Ion battery
ZQ630 Plus: 6600 mAh (nominal) 47.5 Wh removable, rechargeable PowerPrecision + Li-Ion battery
Built-in battery charger
Belt clip for unobtrusive and convenient printing (not compatible with extended capacity battery)
Black mark and gap media sensing using fixed center position sensors
Easy-to-use peel and present mode
Technical Specs
Interfaces/Ports
USB Host Yes
Technical Information
Application/Usage Warehouse
Transportation & Logistic
Retail
Mobile
Manufacturing
Healthcare
Barcode Symbology Supported Micro PDF-417
2 and 5 Digits Add-on
Maxi Code
Interleaved 2 of 5
GS1 DataBar (RSS)
FIM Postnet
EAN-8
EAN-13
Data Matrix
Code 93
Code 39
Code 128
Codabar (NW-7)
MSI
MSI PLESSEY
PDF417
Plessey
POSTNET
QR Code
TLC 39
UCC/EAN 128
UPC-A
UPC-E
2D
AZTEC
Maximum Print Width 48 mm (1.89")
Recommended Use Label/Receipt Print
Features Water Resistant
Belt Clip
Peel Facility Yes
Print Color Capability Monochrome
Maximum Print Length 813 mm
Character Sets Universal Font Scaling Technology (UFST)
English
Agfa Monotype
Fonts Included Chinese Korean fonts
Ingress Protection (IP) Rating IP54
Maximum Print Resolution (dpi) 203
Software
Operating System Supported
Link-OS
Cutter
Cutter Yes
Cutter Type Tear Bar
Memory
Flash Memory 512 MB
Standard Memory 256 MB
Battery Information
Battery Chemistry Lithium Ion (Li-Ion)
Battery Capacity 3250 mAh
Battery Included Yes
Display & Graphics
Display Screen Yes
Screen Size 5.1 cm (2")
Display Screen Type LCD
Fonts & Emulation
Language Emulation CPCL
ZPL
XML
EPL
Miscellaneous
Platform Supported SPARC
Android
PC
Energy Star Yes
Physical Characteristics
Weight (Approximate) 600 g
Height 72.4 mm
Width 91.4 mm
Depth 170.9 mm
Network & Communication
Bluetooth Yes
Ethernet Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Ethernet Technology Fast Ethernet
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ61HAXAA0400
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ610 Plus
Product Name ZQ610 Plus Direct Thermal Printer
Product Series ZQ600 Plus
Brand Name Zebra
Media Types & Handling
Media Thickness 165.1 µm
Maximum Roll Diameter 34.90 mm
Media Type Receipt
Linered Label
Label
Media Sensor Gap Sensor
Label Present Sensor
Black Mark Sensor
Maximum Label Width 55.40 mm
