Product Description
Zebra's ZQ500™ Series just got tougher. The premium ZQ511™ and ZQ521™ printers - both available in RFID models - give you best-in-class, rugged mobile printing for applications in any industry. Experience ultimate durability. Engineered for tough, demanding indoor and outdoor conditions, these printers can withstand significant drops, tumbles, accidents and environmental extremes that are common in mobile workplaces. Additional features, enhanced durability, and military-grade design mean this printer will work as hard as you do.
PRINT IT ALL: RECEIPTS, RFID TAGS, LABELS, AND LINERLESS
Optimized for on-demand receipt printing in 3" (72mm) and 4" (104mm) print widths, the ZQ511 and ZQ521 printers also print a variety of labels including UHF RFID tags for all your tracking needs. Zebra's comprehensive RFID portfolio is the only one to include mobile printers to help you reduce errors, and print and encode RFID labels on the go.
TOUGH. RELIABLE. BUILT TO ENDURE.
The Most Rugged Printers on the Market
You need a mobile printer that can handle serious abuse. Designed and certified to meet MIL-STD 810G for drop and shock, and tumble tested per the IEC68-2-32 spec to handle 1300 tumbles from 3.3' (1M), the ZQ511 and ZQ521 printers can withstand more than the average mobile printer.
Protection from solid and liquid ingress is no problem with an IP54 rating right out of the box without the need for a protective case.
If this isn't enough to convince you that these are ultra-rugged mobile printers, we also offer an optional exoskeleton case that increases our standard drop testing from 6.6' to 10' and improves the IP rating to IP65.
Built to Last
New over-molding helps increase longevity and keeps your ZQ500 Series looking good over the printer's life.
Tech Specification:-
Interfaces/Ports
USB Yes
Memory
Standard Memory 256 MB
Power Description
Power Source Battery
Software
Operating System Supported
Link-OS
Display & Graphics
Display Screen Yes
Display Screen Type LCD
Fonts & Emulation
Language Emulation ZPL
CPCL
ESC/POS
ZBI
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
RFID Yes
Near Field Communication (NFC) Yes
Physical Characteristics
Weight (Approximate) 630.5 g
Form Factor Portable
Height 61 mm
Width 119.4 mm
Depth 149.9 mm
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ51-BAW100A-00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ511
Product Name ZQ511 Direct Thermal Printer
Product Series ZQ500
Brand Name Zebra
Media Types & Handling
Media Thickness 160 µm
Maximum Roll Diameter 50.80 mm
Media Type Receipt
Gap
Linerless
Black Mark
Label
Tag
Media Sensor Gap Sensor
Black Mark Sensor
Maximum Label Width 80.01 mm
Miscellaneous
Platform Supported PC
Android
iOS
Power Cable Localization AUS
ID
India
KR
LK
MY
NZ
TW
Technical Information
Application/Usage Mobile
Barcode Symbology Supported UCC/EAN 128
TLC 39
Standard 2 of 5
QR Code
POSTNET
Plessey
Planet Code
PDF-417
UPC-E with EAN 2 or 5-Digit Extension
UPC-A
UPC-E
MSI PLESSEY
MSI
Micro PDF-417
Maxi Code
LOGMARS
ISBT-128
Interleaved 2 of 5
Industrial 2 of 5
GS1 DataBar
FIM
EAN-8
EAN-13
Data Matrix
Code 93
Code 49
2 and 5 Digits Add-on
2D
AZTEC
Codabar
Codabar (NW-7)
Codablock
Code 11
Code 128
Code 39
Maximum Print Width 71.88 mm (2.83")
Recommended Use Label/Receipt Print
Features Dual Sided Printer
Drop Resistant
Rugged
Print Technology Direct Thermal
Mobile Device Printing Yes
Print Color Capability Monochrome
Maximum Print Length 990.60 mm
Character Sets Universal Font Scaling Technology (UFST)
Cyrillic
Hebrew
Arabic
Agfa Monotype
Real-Time Clock Yes
Maximum Print Resolution (dpi) 203
What's in the box?
Zebra ZQ511 Mobile Printer with Linerless Platen and Bluetooth 4.1
3250 mAh Battery
Belt Clip
Product Specifications
Mono Print Speed 127mm/sec.
Max. Print Resolution 203 dpi
256 MB Standard Memory
50.80mm Max. Roll Diameter
ZPL, CPCL, ESC/POS & ZBI
USB, Bluetooth & Wireless
2 Years Limited Warranty
Brochure for Zebra ZQ511 (ZQ51-BAW100A-00) 3" BT4/WLAN Mobile Label Printer
