Product Description
Invest in the best: premium features, maximum performanceand unmatched security for years of quality printing
You need a premium, quality printer that's built to perform flawlessly - day in and day out. Rely on Zebra's ZD621 desktop printers, advancing the proven and popular GX Series printers. Don't compromise. Get it all: an innovative new architecture to power our ever-expanding printer capabilities and software. Unmatched security that's constantly evolving to safeguard your sensitive data and shield you from cyberattacks. Enhanced features, communication and media-handling options that you can add whenever you're ready. An optional full-color LCD touch display with intuitive menu. And, increased remote-management capabilities. Together, these give you outstanding print performance, years of optimal use, industry-leading reliability and unparalleled intelligence and security. Everything you need in a printer to keep your workflows fluid and business moving forward.
Elevating a Proven Winner | Extending the G-Series Legacy
Zebra's GX Series printers are known for quality and premium performance. As you select your next printer, you can be confident that the next-generation ZD621 includes everything you loved in those legacy printers, and builds on this heritage to deliver best-in-class features for this new era of intelligence and forward adaptability.
Expect the Best | Premier Printing Performance
Rely on the ZD621 to help you power through - day after day. From outstanding print quality to portability for application flexibility to emerging technology to field-installable options, the ZD621 stands apart. Available in direct thermal, thermal transfer, healthcare and RFID models, the ZD621 supports a wide variety of use cases.
Operate with Ease | Simple to Deploy, Use, Manage and Secure
Backed by Zebra's innovative Print DNA software suite, the ZD621 is incredibly simple to operate. Deploy it anywhere with setup tools, wizards and emulation capabilities. The intuitive user interface is easy to use with minimal training and allows you to see status at a glance with the five LED icons. Take advantage of robust remote management capabilities that alleviate IT burdens. And, built-in security hardens your infrastructure from cyberattacks.
Put it to Work for Years | Designed to Perform Today and Tomorrow
Technology is constantly advancing. So can your ZD621. Featuring an innovative architecture, it's engineered to power future printing. In comparison, it's 30% more powerful than the ZD620 Series and nearly 300% more than the GX Series. This gives you the ability to run more tasks, perform more operations simultaneously, maintain security and be ready for what's next.
Features
Print methods: Direct Thermal
ZPL and EPL programming languages
5 status icon, 3 button user interface
Ethernet, Serial, USB 2.0, USB Host
Printer setup mobile app for Android & iOS via BLE (Bluetooth Low Energy 5) connection
Real Time Clock (RTC)
Media dancer for excellent print quality
OpenACCESS™ for easy media loading
Dual-wall frame construction
ENERGY STAR® certified
Technical Specs
Memory
Standard Memory 256 MB
Software
Operating System Supported
Link-OS
Interfaces/Ports
USB Yes
Serial Port Yes
USB Host Yes
Power Description
Power Source AC Supply
Frequency 60 Hz
50 Hz
Display & Graphics
Display Screen Yes
Screen Size 10.9 cm (4.3")
Touchscreen Yes
Display Screen Type LCD
Technical Information
Application/Usage Retail
Manufacturing
Healthcare
Desktop
Transportation & Logistic
Barcode Symbology Supported UPC
UPC-A
UPC-E
Standard 2 of 5
QR Code
POSTNET
Industrial 2 of 5
Planet Code
Plessey
Code 49
Code 39
Code 128
Code 11
Codablock
Codabar
AZTEC
PDF417
Code 93
Data Matrix
EAN 2 or 5 Digit Extension
EAN-13
EAN-8
Interleaved 2 of 5
ISBT-128
LOGMARS
Maxi Code
Micro PDF
MSI
Maximum Print Width 104 mm (4.09")
Recommended Use Label/Receipt Print
Connectivity Technology Wired
Features Status Indicator
Dual Wall Frame
Mobile Device Printing Yes
Print Color Capability Monochrome
Real Time Clock Yes
Maximum Print Resolution (dpi) 203
Network & Communication
Bluetooth Yes
Ethernet Yes
Wireless LAN Yes
Near Field Communication (NFC) Yes
Physical Characteristics
Weight (Approximate) 1.63 kg
Height 149.9 mm
Width 177.8 mm
Depth 221 mm
Fonts & Emulation
Language Emulation EPL
EPL2
EZPL
XML
ZBI
ZPL
ZPL II
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZD6A042D3PF00EZ
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZD621
Product Name ZD621 4-Inch Desktop Printer
Product Series GX
Brand Name Zebra
Miscellaneous
Platform Supported Android
PC
iOS
Certifications & Standards
cTUVus
Environmentally Friendly Yes
Energy Star Yes
Power Cable Localization AUS
UK
JP
EU
Media Types & Handling
Media Thickness 190 µm
Maximum Roll Diameter 127 mm
Media Type Label
Receipt
Reflective
Roll Fed
Tag
Tag Stock
Gap
Fanfold
Wristband
Continuous Roll
Continuous Receipt
Black Mark
Die-cut Label
Media Sensor Moveable Reflective/Black Mark Sensor
Multi-position Transmissive/Gap Sensor
Full Width Sensor
Label Taken Sensor
Maximum Label Width 118 mm
Maximum Label Length 991 mm
What's in the box?
ZD621 Thermal Transfer Printer
Empty Ribbon Take-Up Cores (1 in. and 0.5 in.)
300 m Ribbon Core Adapters
AC Power Supply
Power Cord
USB Cable
Quick Start Guide
Regulatory Guide
