Get more: Extra features, quality construction, exceptional value
Not all printers are created equally, especially basic models. To reduce costs, value printers are often constructed using less expensive components and fewer features. Many fail to perform under more demanding duty cycles, create delays and downtime for repairs, and require replacement after only a few years of use. Instead of conserving budget, customers are left with greater expense and hassle. Zebra does it differently. Meet the exception. The ZD230 desktop printer gives you extra features and reliable operation at an affordable price-both at the point of purchase and across the entire lifecycle. Engineered with Zebra quality, it boasts a dual-wall construction. And, it offers wireless connectivity for networked, remote printing. Built to last for years, the ZD230 provides an outstanding return on your investment.
Get Printing Quickly
The ZD230 is simple to install and begin printing right out of the box. Easily replace legacy printers using ZPL, EPL, or non-Zebra command languages. USB, Ethernet, Wi-Fi, and Bluetooth® connectivity options enable universal interoperability. The ZD230 can accommodate a 300 M ribbon roll to lengthen the time between media changes. And, Zebra's OpenACCESS™ clamshell design expedites media replacement. It's also ENERGY STAR® qualified to reduce your operational expenses.
Just the Features You Need
This 4-inch printer produces labels quickly, up to 6" per second, to keep your workflows moving. Increased memory allows you to store more fonts and graphics. A single LED indicator and a single button for feed/pause make it easy to operate and identify the printer status. Choose from direct thermal or thermal transfer models, and add an optional factory-installed peeler or cutter. The ZD230 features a core set of Print DNA software applications, powered by Link-OS Basic, to deliver a cost-effective and dependable print experience. It is ideal for use in transportation and logistics, light manufacturing, retail and healthcare applications to print a variety of tickets, tags, passes, label,s and receipts.
Backed by Zebra's Worldwide Service and Support
Access repair support services, live-agent technical support and software support quickly anywhere around the globe through Zebra and its trusted network of more than 10,000 partners. Zebra OneCare™ provides enhanced coverage that exceeds standard warranty for normal wear and tear, priority repair turnaround times at the depot, and more for a tiny fraction of the cost of a single repair.
Consistently Exceptional Zebra Certified Supplies
Printing supplies can impact everything from printhead lifespan to operational efficiency. That's why we design, produce, and rigorously pretest our own line of thermal printing supplies to ensure consistent, optimized performance in your Zebra printer-and peace of mind for you. For industry-leading quality, service, and thermal printing expertise, choose Zebra Certified Supplies.
Optimize your workflows by sharing the resources of the printer via Ethernet connectivity
Produce high-quality documents with this monochrome printer to increase your productivity
Use a Thermal Transfer Printer for its versatility and compact design, as well as its high-resolution and durable printing capabilities
This printer produces high-quality labels and receipts
Tech Specification:-
Cutter
Cutter Yes
Memory
Standard Memory 128 MB
Interfaces/Ports
USB Yes
Serial Port No
Network & Communication
Ethernet Yes
Network Ready Yes
Miscellaneous
Certifications & Standards
IEC 60950-1
EN55022 Class B
EN55024
EN61000-3-2
EN61000-3-3
FCC Class B
ICES-003
FCC 15.209;15.247(d)
IC RSS 247
EN 300 328
EN 301 893
EN 62311
cTUVus
CE Marking
VCCI
C-Tick
S-Mark
CCC
CU
BSMI
KCC
SABS
IN-Metro
BIS
NOM
cTUVus
Energy Star Yes
Power Cable Localization UK
Power Description
Power Source AC Supply
Frequency 60 Hz
50 Hz
Physical Characteristics
Weight (Approximate) 1.10 kg
Height 191 mm
Width 197 mm
Depth 267 mm
Fonts & Emulation
Language Emulation EPL
EPL2
ZPL II
ZPL
XML
General Information
Product Type Thermal Transfer Printer
Manufacturer Part Number ZD2304230PC00EZ
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZD230
Product Name ZD230 4-inch Value Desktop Printer
Product Series ZD200
Brand Name Zebra
Media Types & Handling
Maximum Roll Diameter 127 mm
Media Type Continuous Label
Continuous Receipt
Die-cut Label
Wristband
Gap
Label
Receipt
Roll Fed
Tag Stock
Black Mark
Fanfold
Media Sensor Moveable Sensor
Black Mark Sensor
Gap Sensor
Maximum Label Width 112 mm
Maximum Label Length 991 mm
Technical Information
Application/Usage Transportation & Logistic
Manufacturing
Retail
Healthcare
Desktop
Barcode Symbology Supported Code 49
Codablock
Data Matrix
EAN With 2 and 5 Digit Extension
EAN-13
EAN-8
Industrial 2 of 5
Interleaved 2 of 5
ISBT-128
LOGMARS
Maxi Code
Codabar
Aztec Code
Code 93
Code 11
Code 128
Code 39
UPC-E
UPC-A
UPC
Standard 2 of 5
QR Code
POSTNET
Plessey
Micro PDF
MSI
PDF417
Planet Code
Maximum Print Width 104 mm (4.09")
Recommended Use Label/Receipt Print
Connectivity Technology Wired
Features Dispenser
Dual Wall Frame
Status Indicator
Print Technology Thermal Transfer
Peel Facility Yes
Print Color Capability Monochrome
Real Time Clock No
Maximum Print Resolution (dpi) 203
