Product Description
Specifications are provided for reference and are based on testing the ZT411 printer using genuine Zebra supplies. Results may vary in actual application settings or when using other-than-recommended Zebra supplies. Zebra recommends always qualifying any application with thorough testing
Features
Save time and money for your business by using one printer for all your employees
Produce high-quality documents with this monochrome printer to increase your productivity
Use Thermal Transfer Printer for their versatility and compact design, as well as their high-resolution and durable printing capabilities
Delivers high-speed, hassle-free labelling solution for your business needs
Technical Specs
Fonts & Emulation
Language Emulation EZPL
Memory
Standard Memory 256 MB
Display & Graphics
Display Screen Yes
Screen Size 10.9 cm (4.3")
Touchscreen Yes
Technical Information
Application/Usage Industrial
Barcode Symbology Supported Code 128 UCC
Code 39
Code 49
Code 93
Data Matrix
EAN 2 or 5 Digit Extension
EAN-13
EAN-8
Industrial 2 of 5
Interleaved 2 of 5
ISBT-128
LOGMARS
Maxi Code
Micro PDF
MSI
PDF-417
Planet Code
Plessey
POSTNET
QR Code
RSS-14
Standard 2 of 5
TLC 39
UPC
UPC-A
UPC-E
2D
AZTEC
Codabar
Codablock
Code 11
Code 128 (A/B/C)
Maximum Print Width 103.89 mm (4.09")
Recommended Use Label Print
Connectivity Technology Wired & Wireless
Print Color Capability Monochrome
Maximum Print Length 3.99 m
Maximum Print Resolution (dpi) 203
Interfaces/Ports
USB Yes
Serial Port Yes
USB Host Yes
Power Description
Power Source AC Supply
Frequency 50 Hz
60 Hz
Miscellaneous
Platform Supported PC
Energy Star Yes
Power Cable Localization AUS
EU
UK
JP
Network & Communication
Bluetooth Yes
Ethernet Yes
Ethernet Technology Fast Ethernet
RFID Yes
Bluetooth Version 4.1
On-metal RFID Yes
Physical Characteristics
Weight (Approximate) 16.33 kg
Height 324 mm
Width 269 mm
Depth 495 mm
Product Color Black
Color Family Black
General Information
Product Type Thermal Transfer Printer
Manufacturer Part Number ZT41142T5P00C0Z
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZT411
Product Name ZT411 Industrial Printer
Product Series ZT400
Brand Name Zebra
Media Types & Handling
Media Thickness 250 µm
Maximum Roll Diameter 203 mm
Media Type Notch
Reflective
Label
Die-cut Label
Continuous Label
Black Mark
Media Sensor Black Mark Sensor
Gap Sensor
Maximum Label Width 114 mm
Maximum Label Length 991 mm
What's in the box?
Printer unit
Starter roll of label stock
Power cord
User guide
Safety guide
Product Specifications
Max. Mono Print Speed 356mm/s
Max. Print Resolution 203dpi
256 MB Standard Memory
Max. Roll Diameter 203 mm
Notch, Label & Die-cut Media
USB, Network & Bluetooth
One-Year Limited Warranty
Brochure for ZEBRA MIDRANGE ZT411 (ZT41142-T5P00C0Z) 4IN 203DPI Industrial Printer
