Product Description
A million units equals a million reasons why the QLn Series made its mark in retail history. Now, it's doing it again, as the ZQ600 Series mobile printer.
The ZQ600 Series delivers all the features needed to maximize associate productivity and customer service. Shop associates can print everything from shelf labels to item tags, markdown labels, and sales receipts, right on the spot. This premium mobile printer takes productivity, ease-of-use, and manageability to a new level with a large colour display, fast 802.11ac and Bluetooth 4.1 wireless connections, class-leading battery technology, and powerful remote management tools.
Features
Apple® iOS, Android and Windows Mobile connectivity
Direct thermal printing of barcodes, text and graphics
CPCL, EPL™ and ZPL® programming languages
512 MB Flash supports downloadable programs, receipt formats, fonts
and graphics (128 MB available for user storage)
3250 mAh (nominal) 23.4 Wh removable, rechargeable PowerPrecision+ Li-Ion battery
Built-in battery charger
Belt clip for unobtrusive and convenient printing (not compatible with extended capacity battery)
Blackmark and gap media sensing using fixed center position sensors
Easy-to-use peel and present mode
Technical Specs
Battery Information
Battery Included Yes
Interfaces/Ports
USB Yes
Memory
Standard Memory 256 MB
Power Description
Power Source Battery
Warranty
Limited Warranty 1 Year
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Near Field Communication (NFC) Yes
Miscellaneous
Package Contents
ZQ620 Mobile Printer
Belt Clip
Rechargeable PowerPrecision+ Li-Ion battery
Platform Supported iOS
PC
Android
Media Types & Handling
Maximum Roll Diameter 66.04 mm
Media Type Receipt
Black Mark
Gap
Label
Black Bar
Liner-free Label
Die-cut Label
Tag
Maximum Label Width 79.38 mm
Maximum Label Length 812.80 mm
Physical Characteristics
Weight (Approximate) 730 g
Form Factor Portable
Height 83.8 mm
Width 116.8 mm
Depth 172.7 mm
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ62-AAWAA00-00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ620
Product Name ZQ620 Mobile Printer
Product Series ZQ600
Brand Name Zebra
Technical Information
Application/Usage Mobile
Maximum Print Width 72 mm (2.83")
Recommended Use Receipt Print
Maximum Print Resolution 203 dpi
Maximum Mono Print Speed 115 mm/s
Mobile Device Printing Yes
Print Color Capability Monochrome
Maximum Print Length 812.80 mm
What's in the box?
ZQ620 Mobile Printer
Belt Clip
Rechargeable PowerPrecision+ Li-Ion battery
Product Specifications
Max. Mono Print Speed 115mm/sec.
Max. Print Resolution 203 dpi
256MB Standard Memory
72mm (2.83") Max. Print Width
CPCL, EPL & ZPL Languages
USB, Wireless & Bluetooth
One Year Limited Warranty
Brochure for Zebra ZQ620 (ZQ62-AAWAA00-00) 3" WIFI/BT Mobile Label Printer
