Product Description
Realise outstanding computer graphics design arts potentials with innovative print technology and industry-leading finish, from an 11 colour, 24-inch large-format printer.
Inspire stunning computer graphics design creation with a super-wide colour gamut
Produce powerful computer graphics design prints in vivid colour with Canon’s 11-colour large format printer with fluorescent capabilities. Convenient features support professional output workflows, so you can push your creative limits without compromising on productivity.
Superior colour gamut
Elevate computer graphics with vivid, superior quality printing, using a wide colour gamut that features five new colours – red, orange, green and violet – plus the fluorescent pink, capable of producing neon and pastel shades.
Professional quality prints
The imagePROGRAF GP-2000 is the world’s first PANTONE™(1) calibrated printer(2) for PANTONE PASTEL & NEON GUIDE Coated(3), in addition to 99% coverage from the PANTONE FORMULA GUIDE Solid Coated
High productivity
Multifunction roll systems and Smart Roll Paper support the delivery of professional quality output, while hot swap ink tanks allow inks to be replaced without disrupting the print process.
Security assured
Security Print feature with PIN access helps provide protection against loss or leakage, allowing you to print with peace of mind that all your data is being managed securely.
Specifications in detail
Printer Technology
Printer Type 11 Colour 24"
Print Technology Canon Bubblejet on Demand 11 colours integrated type (12 chips per print head x 1 print head)
Print Resolution 2,400 x 1,200 dpi
Number of Nozzles Total: 18,432 nozzles MBK, PBK, C, M, Y, GY, R, O, G, V, FP: 1,536 nozzles each
Line Accuracy ±0.1% or less
User adjustments necessary. Printing environment and media must match those used for the adjustments.
CAD paper required: Plain paper, CAD tracing paper, coated paper, CAD translucent matte film only
Nozzle Pitch 600 dpi x 2 includes Non-firing nozzle detection and compensation system
Ink Droplet Size minimum 4 pl per colour
Ink Capacity Bundled Starter Ink: 330 ml (MBK), 160 ml (Others)
Sales Ink: 160 ml, 330 ml, 700 ml
Ink Type Pigment inks: 11 colour MBK, PBK, C, M, Y, GY, R, O, G, V, FP
OS Compatibility Microsoft Windows 32-bit: 7, 8.1, 10
Microsoft Windows 64-bit: 7, 8.1, 10, Windows Server 2008R2, 2012, 2012R2, 2016, 2019
Apple Macintosh: macOS 10.13.6 - macOS 11
Printer Languages PDF (Ver.. 1.7), JPEG (Ver. JFIF 1.02)
Standard Interfaces
USB A Port: USB Memory Direct Print for JPEG/PDF files
USB B Port: Built-in Hi-Speed USB
Ethernet : IEEE 802.3 10base-T, IEEE 802.3u 100base-TX / Auto-Negotiation, IEEE 802.3ab 1000base-T / Auto-Negotiation, IEEE 802.3x Full Duplex
Wireless LAN : IEEE802.11n/IEEE802.11g/IEEE802.11b
*Please refer to the user manual on how to activate/deactivate the wireless LAN
Memory
Standard Memory 3GB Expansion slot: No
Hard Drive 500GB (Encrypted)
Print Speed
Poster Plain Paper (A1): 00:59 (Fast) 01:37 (Standard)
Heavy coated Paper (A1): 01:37 (Standard) 03:09 (High Quality)
Photo Paper (A1): 03:08 (Standard) 04:40 (High Quality)
Media Handling
Media Feed and Output Upper Roll Paper: One Roll, Front-loading, Front Output
Lower Roll Paper (option): One Roll, Front-loading, Front Output
Cut Sheet: Front-loading, Front Output (Manual feed using media locking lever)
Media Width Roll paper: 152.4 mm - 610 mm Cut sheet: 152.4 mm - 610 mm
Media Thickness Roll/Cut: 0.07 mm - 0.8 mm
Minimum Printable Length Roll paper: 101.6 mm Cut sheet: 203.2mm
Maximum Printable Length Roll paper: 18 m (Varies according to the OS and application) Cut sheet: 2133.6mm (With Stand)
Maximum Media Roll Diameter 170 mm
Media Core Size Internal diameter of roll core: 2"/3"
Margins Recommended Area Roll paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm, Cut sheet: Top: 20 mm, Bottom: 20 mm, Side: 3 mm
Margins Printable Area
Roll paper : Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll paper (borderless print) : Top: 0 mm, Bottom: 0 mm, Side: 0 mm
Cut sheet : Top: 3 mm, Bottom: 20 mm, Side: 3 mm
Media Feed Capacity Roll Paper: 1 roll Cut Sheet: 1 sheet
Media Take-Up Roll Unit: A dual-direction roll take-up unit allowing the print surface to be wound inside or outside of the roll.
Borderless Printing Width (Roll Only) [Recommended] 515 mm (JIS B2), 594 mm (ISO A1), 10", 14", 17", 24" [Printable] 257 mm (JIS B4), 297 mm (ISO A3), 329 mm (ISO A3+), 420 mm (ISO A2), 6", 8", 12", 15", 16", 20", 22”, 300 mm, 500 mm, 600 mm, and custom roll width (152.4 - 610 mm)
Maximum Number of Delivered Prints Standard position: 1 sheet
Flat position: A2 landscape, glossy paper up to 10 sheets, coated paper up to 20 sheets (excludes strong curled condition)
Power and Operating Requirements
Power Supply AC 100-240V (50-60Hz)
Power Consumption Operation: Approx. 99W Sleep mode: Approx. 2.3W
Default setting for the time to enter the Sleep mode: Approx. 5 Minutes
Power off: Approx. 0.2W
Operating Environment Temperature : 15~30℃, Humidity : 10~80% RH (no dew condensation)
Acoustic Noise (Power/Pressure) Operation: 48 dB (A) (Plain paper, Standard mode, Poster) (Measured on ISO7779 standard)
Standby: 35 dB (A) or less
Operation: 6.5 Bels (Plain paper, Standard mode, Poster) (Measured on ISO7779 standard)
Regulations
Europe: CE mark
Other Countries: CB certification
Environment Certificates TUV, CB
Dimensions and Weight
Physical Dimensions and Weight 1100 x 984 x 1168 mm (Basket Open)
1100 x 766 x 1168 mm (Basket Closed)
102 kg (Main Unit + Stand + Basket, including Roll Holder Set, excluding ink and print head)
Packaged Dimensions and Weight
Printer (Main unit with pallet): 1324 x 902 x 1042 mm 125 kg
Stand + Basket : 1111 x 797 x 223 mm 23 kg
Roll Unit : 1244 x 562 x 461 mm 26 kg
What's Included
What's in the Box?
Printer, 1 print head, 1 roll holder (spool), 3 inch paper core attachment, Power Cable, 1 set of starter ink tanks, Set up guide, Printer Stand Setup Guide, Quick Guide, Safety/Standard Environment leaflet, User software CD-ROM (Win), PosterArtist Lite CD-ROM, EU Biocide Sheet, Important Information Sheet
Software Included: imagePROGRAF GP Printer Driver and PosterArtist Lite
Other software is available for download from the Web.
Options
Optional Items Printer Stand: SD-21
2/3" Roll Holder : RH2-29
Roll Unit : RU-23
Consumables
User Replaceable Items Ink Tank : PFI-2100 (160ml), PFI-2300 (330ml), PFI-2700 (700ml)
Print Head: PF-10
Cutter Blade: CT-07
Maintenance Cartridge: MC-30
